Van Den Hul DDT II Special
Tillverkarens produktinformation
A custom handbuilt moving coil cartridge with VDH-type 1 tip, boron cantilever, matched crystal silver-wire coils and 0.65 mV/channel.
The designation “Special” in this cartridge’s name indicates important improvements over its previous version:
The cartridge is equipped with a thicker frontpole and an extra small magnet, both further enhancing its resolution capabilities and output voltage.
The cartridge’s name DDT stands for Depth, Detail and Timbre.
Specifikationer:
- Stylus shape vdh – i
- Stylus radii 3 x 85 micron
- Frequency range 5 – 50.000 hz
- Tracking force 13.5 – 15.0 mn
- Static compliance 28 micron/mn
- Tracking ability 70 – 80 micron
- Output voltage 0.65 mv rms
- Channel unbalance < 0.75 db
- Channel separation > 35 / > 30 db
- Stylus tip mass 0.35 milligram
- System weight 8.2 gram
- Vertical tracking angle 22 degrees
- Load capacitance see (*2)Load impedance 200 ohm
- Eff tone arm mass 8 – 12 gram
- Moving coil resistance 9 ohm +/- 10%
