Beskrivning
Description
Passive DI box. Jack input with paralell ”THRU” output, transformer balanced XLR output. Attenuable input sensitivity, can handle both line level and speaker level signals
Specifications
- Product type: DI Boxes
- Type: Passive
- Channels: 1
- Inputs: 1
- Input connectors: 6.3 mm Jack
- Max. input level: + 54 dBu
- Input impedance: (@ 60 Hz) 60k Ohm(s)
- Input pad: 0 / -30 dB
- Number of outputs: 1
- THRU outputs/channel: 1
- Output connectors: 6.3 mm jack, XLR
- Max. output level: + 4 dBu
- Output impedance: 600 Ohm(s)
- Frequency response: 20 – 20000
- Transformer balanced: Yes
- Ratio: 10 : 1
- Controls: Attenuator, ground lift
- Cabinet material: Sheet steel
- Cabinet surface: Powder coated
- Width: 110 mm
- Depth: 73 mm
- Height: 42 mm
- Weight: 0.34 kg
